1. Product Introduction

The 6301-RS is a single-row deep groove ball bearing measuring 12 × 37 × 12 mm, fitted on both sides with NBR rubber contact seals. The double-lip seal presses lightly against the inner ring land and closes the bearing completely, holding water, detergent, dust and fine slurry outside while keeping the factory grease inside. Rings and balls are made of GCr15 chrome bearing steel hardened to HRC 60-62 and ground to P5 (ABEC-5) precision, giving Z4 noise and V4 vibration running quality. For machines that are washed down, splash exposed or run in a wet floor environment, this sealed bearing keeps rotating smoothly for its whole grease life without any relubrication.

2. Product Features

• Double-lip rubber contact seals: two NBR seals close the bearing on both faces, block splash water, foam and fine slurry, and keep the grease from washing out or leaking.
• Water and dust protection: the contact lip seals against the inner ring land, so the bearing survives wash-down routines and humid, wet floors that would ruin an open or shielded bearing.
• P5 precision grade: controlled bore, outside diameter and raceway geometry hold a precise fit and low run-out even after the seal preload is applied.
• Z4 noise, V4 vibration: quiet-running groove finish and graded balls keep the noise low, which is important on cleaning machines that work close to staff and customers.
• Grease sealed for life: pre-filled with lithium base grease, so the maintenance schedule of the machine needs no lubrication point for this bearing.
• Load capacity in a compact size: 9.72 kN dynamic and 5.08 kN static rating carries the brush drive load plus belt tension with a comfortable safety margin.
• Standard envelope: the 12 × 37 × 12 mm dimension matches the international 6301 series for direct replacement of RS, 2RS, ZZ or open versions.

3. Product Advantages

Seal tightness, seal torque and running noise are checked on every production lot, and the rubber compound is selected for resistance to water, detergent and dilute cleaning chemicals, so the seal does not harden or swell in service. For the machine builder this means fewer warranty claims from wet working conditions: the bearing keeps its grease, the grease keeps its film, and the shaft keeps its position. Factory-direct supply covers P5 or higher precision, selected clearance, low-torque seal options, stainless or ceramic variants and neutral packaging, with stock available for short lead times. Where a hoist or a pump can live with a shield, a wet-floor machine cannot — this is the version to specify for splash, foam and wash-down duty.

4. Product Technical Parameters

5. Product Applications

The typical application of the 6301-RS is the brush drive motor of a walk-behind floor scrubber. That motor sits low on the machine, only a few centimetres above a wet concrete floor, and works in a cloud of water, detergent foam and dirty slurry thrown up by the rotating brush. The rubber contact seals keep that mixture out of the raceway and keep the grease in, so the brush keeps its full torque and the motor does not seize after a few months of daily cleaning shifts. The same seal also absorbs the small axial float of the brush deck without letting water past, which is what a shield cannot do.

Further applications of the sealed version are car wash and pressure cleaning equipment, food industry wash-down conveyors, swimming pool and fountain pump shafts, agricultural sprayer pumps, outdoor gate and door operators and any drive that is exposed to splash water, steam or humid air.
