6201 6202 6203 electric motor bearing with ISO9001:2015 certification

Detail Information

Product Description

Detail Information

Product Description

The type of deep groove ball Bearing 62series component materials used in automobile, tractor, machinery, motor, water pump, agricultural machinery and textile machinery. Its wide application, simple design, non - separation, suitable for high - speed, reliable operation, low maintenance costs.The tight consistency between deep raceway and ball enables bearings to bear axial and radial force.

Product Parameters:

轴承代号 Bearing Code	内径 d 毫米英寸 Bore d mm inch	外径 D 毫米英寸 Outer Diameter D mm inch	宽度 W 毫米英寸 Width W mm inch	倒角 r 毫米英寸 Radius r mm inch	基本额定负荷 KN "Basic Loading KN"		极限转速 "Maximum Run out Sprrd"		重量 Kg/pc Weight Kg/pc
轴承代号 Bearing Code	内径 d 毫米英寸 Bore d mm inch	外径 D 毫米英寸 Outer Diameter D mm inch	宽度 W 毫米英寸 Width W mm inch	倒角 r 毫米英寸 Radius r mm inch	动负荷 Cr Dynamic Cr	静负荷 Cor Static Cor	脂润滑 r/min Grease r/min	油润滑 r/min Oil r/min	重量 Kg/pc Weight Kg/pc
624	4 .1570	13 .5120	5 .197	0.2 .0079	1.33	0.485	40000	48000	0.0027
625	5 .1970	14 .5510	5 .197	0.2 .0079	1.33	0.505	40000	38000	0.0047
626	6 .2360	19 .7480	6 .2360	0.3 .012	2.34	0.885	32000	30000	0.0084
627	7 .2756	22 .8661	7 .2756	0.3 .012	3.35	1.4	26000	34000	0.013
628	8 .3149	24 .9448	8 .3149	0.3 .012	4	1.59	24000	32000	0.017
629	9 .3543	26 1.0236	8 .3149	0.3 .012	4.55	1.96	22000	30000	0.02
6200	10 .3937	30 1.1811	9 .3543	0.6 .024	5.1	2.39	19000	26000	0.032
6201	12 .4724	32 1.2598	10 .3937	0.6 .024	6.1	2.75	18000	24000	0.037
6202	15 .5906	35 1.3780	11 .4331	0.6 .024	7.75	3.6	17000	22000	0.045
6203	17 .6693	40 1.5748	12 .4724	0.6 .024	9.6	4.6	16000	20000	0.066
6204	20 .7874	47 1.8504	14 .5512	1.0 .039	12.8	6.65	14000	18000	0.106
6205	25 .9843	52 2.0470	15 .5906	1.0 .039	14	7.85	12000	16000	0.128
6206	30 1.1811	62 2.4409	16 .6299	1.0 .039	19.5	11.3	10000	13000	0.199
6207	35 1.3780	72 2.8346	17 .6693	1.1 .043	25.7	15.3	8800	10000	0.287
6208	40 1.5748	80 3.1496	18 .7087	1.1 .043	29.1	17.8	7700	9200	0.367
6209	45 1.7717	85 3.3465	19 .7480	1.1 .043	32.5	20.4	6800	8200	0.416
6210	50 1.9685	90 3.5433	20 .7874	1.1 .043	35	23.2	6100	7300	0.462
6211	55 2.1654	100 3.9370	21 .8268	1.5 .059	43.5	29.2	5500	6600	0.602
6212	60 2.3622	110 4.3307	22 .8661	1.5 .059	52.5	36	5000	6000	0.789
6213	65 2.5591	120 4.7244	23 .9055	1.5 .059	58.5	40.5	4800	5800	0.99
6214	70 2.7559	125 4.9213	24 .9449	1.5 .059	63.7	45	4600	5600	1.1
6215	75 2.9528	130 5.1181	25 .9843	1.5 .059	68.9	49	4400	5400	1.2
6216	80 3.1496	140 5.1181	26 1.0236	2.0 .078	72.5	53	4200	5300	1.4
6217	85 3.3613	150 5.9111	28 1.1114	2.0 .078	84	62	4300	5000	1.76
6218	90 3.5374	160 6.3423	30 1.1823	2.0 .078	96	71	4000	4800	2.18

Application Area:
1. Automatic controlling machine
2. Semi-conductor industry
3. General industry machinery
4. Medical equipment
5. Solar energy equipment
6. Machine tool
7. Parking system
8. High-speed rail and aviation transportation equipment, etc.

6201 6202 6203 electric motor bearing with ISO9001:2015 certification

Company Certificate

6201 6202 6203 electric motor bearing with ISO9001:2015 certification

About us
Ningbo Kent bearing company was established in 2003 and is one of the leading bearing manufacturers and exporters in China. Kent specialized in designing and producing high precision deep groove bearing, high speed and low noise ball bearings and pillow block bearings.Products widely exported more than 50 countries with 2 independant brands, namely "BUGAO" and "NBKT".

6201 6202 6203 electric motor bearing with ISO9001:2015 certification

Contact information:

Address:

No.5,Tangchuangyuan,Yangshan Industrial Zone,Ditang Sub-district,Yuyao City,Ningbo
City,Zhejiang Province,China.
